MB800

Interface module for motrona MC800 motion controller.

The MB800 interface module provides instant Modbus connectivity of the MC800 universal motion controller. It is a standard Modbus RTU Slave and provides Modbus functions such as Read Coils, Write Single Coil, Write Multiple Coils, Read Discrete Inputs, Read Holding Registers, Write Multiple Registers and Read Input Registers. The Modbus interface is galvanically isolated and provides both, RS232 and RS485. It supports all common baud rates from 1200 Bit/s to 115200 Bit/s. The module can easily be fitted to the MC800 by plug-in mounting to a prepared slot.

• Internal power supply 3,3 V
• Ambient temperature 0° C ... +60° C / 32° F ... 140° F (operating), -40° C ... +70° C / -40° F ... 158° F (storage)
• 1200 ... 115200 Bit/s Baud rates
• SUB-D-9-pin female, galvanically isolated
